Minelab GPX 5000 User Manual

70
GPX 5000 Range
GPX 4800 Range
Factory Preset
Slow, Medium, Fast
Slow, Medium, Fast
Medium
Tracking Speed
Keeping up with changing ground.
Tracking Ground Balance is the preferred setting when
searching in highly variable mineralisation. Tracking Ground
Balance automatically measures the ground mineralisation
and adjusts the Ground Balance as necessary, to maintain
stability and detection depth. The speed of the Tracking can
be changed to suit the degree of variable mineralisation.
The GPX 5000 and GPX 4800 have three Auto Tracking Speed
options: Slow, Medium & Fast.
The preferred Tracking Speed is the slowest speed which
keeps up with the variability of the ground mineralisation. You
should gradually increase from Slow Tracking Speed, Medium
Tracking Speed, then Fast Tracking Speed as required.
Slow
The Slow Tracking Speed is recommended if seeking out large,
deep targets in variable ground, but you should check your
ground balance often and re-balance (p. 41)
whenever necessary.
Note: If you are detecting in highly variable ground, a
slower sweep speed will give Tracking more time to
re-ground balance.

Minelab GPX 5000 Specifications

General

Technology	MPS, DVT & SETA
Ground Balance	Automatic and Manual
Discrimination	Iron Reject
Display	LCD
Battery Life	Up to 12 hours
Coil	11" Double-D coil
Audio Output	Built-in speaker, headphone jack
Battery	Lithium-ion rechargeable battery
Length	1100 mm - 1300 mm (43.3" - 51.2")
Waterproof	Coil is waterproof; control box is not
Target Identification	Audio only
Weight	2.4 kg (5.3 lbs) including battery
Headphone Jack	6.35 mm (1/4")
