Minelab GPX 5000 User Manual

78
Double D Setting Monoloop (Mono) Setting (with Double D coil)
Strongest Signal
To pinpoint a detected target sweep the general area with the
coil taking note of where the strongest signal is received.
By shortening the length of the sweep it should be possible
to draw an imaginary line in the ground where the strongest
signal is located.
Line up the target at 90° from the initial direction and repeat
the process. The object is located where the two imaginary
lines cross.
Note: With the Coil/Rx switch set to Monoloop or Cancel, when
using a Double D coil, pinpointing will not locate a target in the
centre of the coil; the target will be slightly to the left. The left
edge of the coil can be used to pinpoint shallow targets.
Strongest Signal
Pinpointing
Continued...
Tip: If detecting on loose
dirt or gravel you can
actually draw the lines
using your shoe or pick.

Minelab GPX 5000 Specifications

General

Technology	MPS, DVT & SETA
Ground Balance	Automatic and Manual
Discrimination	Iron Reject
Display	LCD
Battery Life	Up to 12 hours
Coil	11" Double-D coil
Audio Output	Built-in speaker, headphone jack
Battery	Lithium-ion rechargeable battery
Length	1100 mm - 1300 mm (43.3" - 51.2")
Waterproof	Coil is waterproof; control box is not
Target Identification	Audio only
Weight	2.4 kg (5.3 lbs) including battery
Headphone Jack	6.35 mm (1/4")
