SP1B
SK73750/7
PG DRIVES TECHNOLOGY
6
Function Range Res. SP1a SP1b
Forward Acceleration 0.1 to 10s, Fast / Slow 100ms
Forward Deceleration 0.1 to 10s, Fast / Slow 100ms
Reverse Acceleration 0.1 to 10s, Fast / Slow 100ms
Reverse Deceleration 0.1 to 10s, Fast / Slow 100ms
Forward Speed 0 to 100%, Fast / Slow 1%
Reverse Speed 0 to 100%, Fast / Slow 1%
Invert Throttle Polarity Yes / No --
Power Down Timer 0 to 20 minutes 1 min
Help Mode On-line help text --
Diagnostics Trip codes from controller --
Read System Log View stored diagnostic codes --
Read Timer View elapsed running time --
Current Limit 20A to max rating 1A
Motor Compensation 0 to 1 5m
Hold Factor 100 to 420% 4%
Mid Current 0 to 100%, 1 to 255s 1%, 1s
Brake Time 0 to 1s 10ms
Iso Tests 0.1 to 10s, Fast / Slow 100ms
Inhibit Polarity Hi / Lo --
Inhibit Mode 1 to 6 --
Bridge Hold Time 0 to 5s 20ms
Throttle Gain 0 to 1250% 5%
Pulse Reverse Alarm Yes / No --
Wig-wag Throttle Yes / No --
Low Battery Flash Inhibit Yes / No --
Soft-Stop On / Off --
Throttle Deadband 3 to 100% 1%
Output Voltage 20 to 40V 1V
TruCharge Cab Resistance 10 to 250m 5m
TruCharge Cal. 1 to 200 1
Max. Charge Amps 0 to 12A 0.1A
Min. Charge Amps 0 to 12A 0.1A
Erase System Log Clears stored diagnostic codes --
Clear Timer Resets run timer --
ΩΩ
ΩΩ
(3)
(4)
(4)
(1)
(2)
(3)
(1)
(1)
(3)
(4)
(4)
(3)
(3)
