PPAARRTTSS LLIISSTT
* This item is part of an assembly. This item cannot be sold separately due to machining and /or assembly that is required. P/N 2064918 REV. C 8-01
2-100-013 ARMATURE ASSEMBLY 12V F/W
788-015 RETAINING RING
140-010 BEARING -BALL
431-101 HOUSING ASSEMBLY CENTER 3.62
421-065 HOUSING BRUSH END ASSEMBLY 3.62 TXT
2-400-101 PLAIN END HOUSING ASSEMBLY
144-049 FLANGE BEARING (SERVICE ONLY)
880-003 SEAL
880-006 SEAL W/SHIELD
188-036 BRUSH ASSEMBLY
725-050 PAPER TUBE- BRUSH RETENTION
738-036 BRUSH PLATE W/HOLDER
975-040 SPRING -TORSION [2.EA]
337-036 GASKET
701-008 O-RING -THRU BOLT [2.EA]
701-081 O-RING
830-007 SCREW 8-32X1 [2.EA]
830-042 THRU BOLT 10-32X8.83 (2 EA)
990-067 WASHER -STEEL THRUST
990-070 WASHER -NYLATRON [2.EA]
2099094 MOTOR ASSEMBLY -12V 3.625 F/W VARS TXT
2032052 TUBE (COMPOSITE) 36"
2032053 TUBE (COMPOSITE) 42"
1378122 PROPELLER KIT
2091150 PROPELLER- WEEDLESS WEDGE
2151726 WASHER- 5/16 STD SS
2053101 NUT-PROP NYLOC 5/16 SS
2092600 PIN-DRIVE SS
2771812 BRACKET & HINGE ASSEMBLY (INCLUDES- 28—39)
2771911 BRACKET ASSEMBLY (INCLUDES- 28,30,31)
2061910 BRACKET- PLASTIC
2060510 PIN-HINGE
2881300 SCREW-CLAMP, WASHER, RETAINER KIT [2.EA]
2061300 SCREW-CLAMP [2.EA]
2011710 WASHER-CLAMP SCREW [2.EA]
2063605 T-BAR, PLASTIC
2062706 SPRING- (T-BAR)
2067200 LEVER-TILT (RED
2061810 HINGE-PLASTIC
2037301 BUSHING-HINGE [2.EA]
2062800 TENSION BLOCK-SNAP IN
2011385 SCREW, TENSION/KNOB
2060515 PIN, TILT LEVER
2061520 COLLAR-DEPTH
2011365 SCREW-COLLAR/NEW
2052900 STRAIN RELIEF C CORD/SP.C
2090600 LEADWIRE (10 GA) RINGS
2062592 CONTROL BOX,FW, .725 BORE,
2074703 BATTERY GAUGE-12 VOLTS
2303120 SPEED NUT [2.EA]
2061515 COLLAR-CTRL BOX (FRS-WTR)
2990294 CTRL BOX CVR/DECAL ASSEMBLY
2065663 DECAL-COVER MAX 55/T
2990914 HANDLE ASSEMBLY W/O U-JOINT
2302742 SPRING-DETENT (OFF) SS
2302743 SPRING-DETENT (HANDLE-TILT
2303412 SCREW-6-20 X 5/8 SELF TAP [6.EA]
2302745 SPRING-RELEASE BUTTON SS
2303720 RELEASE BUTTON-HANDLE
2060409 HANDLE (TOP HALF) MAXIMIZE
2060415 HANDLE (LOWER HALF)
2303412 SCREW-6-20 X 5/8 SELF TAP [5.EA]
2060005 BEARING-HANDLE PIVOT [2.EA]
2302600 PIN-ACTUATOR
2302850 ACTUATOR-CAM
2302851 ACTUATOR-FWD/REV
2302740 SPRING- (ACTUATOR)
2302741 SPRING-CAM (ZNC PLTD STEEL)
2334006 CONTROL BOARD W/O LEAD 12V
2256300 TIE WRAP-5.5 BLACK
2372100 SCREW-8-18 X 5/8 THD SS [2.EA]
2383407 SCREW-10-24 X 2 PPH ZINC
2383124 NUT-10-24 NYLOCK ZINC
2301310 SCREW-8-18 X 1/2 SS [2.EA]
2301710 WASHER-INSUL. (TRANSF.BAR) [2.EA]
2020700 TERMINAL- RING 3/8 [2.EA]
2263434 SCREW #8 X 1” PPH SS [2.EA]
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
■
23
24
25
26
■
■
*28
29
■
*30
*31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
In the U.S.A., replacement parts may be ordered directly from MINN KOTA Parts Dept.,
706 Holly Lane, P.O.Box 8129, Mankato, Minnesota 56002-8129. In Canada, parts may
be ordered from any of the Canadian Authorized Service Centers shown on the enclosed
list. Be sure to provide the model and serial numbers of your motor when ordering parts.
Please use the correct part numbers from the parts list. Payment for any parts ordered
from the MINN KOTA parts department, may be by cash, personal check, Discover Card,
MasterCard or VISA.To order, call 1-800-227-6433 or FAX 1-800-527-4464.
Fora da América do Norte, queira consul-
tar a lista anexa para identificar o Centro
de Seviço Autorizado MINN KOTA. Não
deixe de incluir o número do MODELO e o
número de SÉRIE do seu motor ao pedir
peças. Sempre use os números corretos
das peças da lista de peças.
Hors de États-Unis, voir la liste ci-jointe pour le
Centre de Service Agréé MlNN KOTA le plus
proche. Lors d'une commande, ne pas oublier
de fournir le numéro de modèle et le numéro
de série du moteur. Toujours mentionner le
numéro de pièce exact figurant sur la liste des
pièces de rechange.
Fuera de los Estados Unidos, consultar la lista
anexa para ubicar el Centro de servicio autor-
izado MINN KOTA. No dejar de incluir el
número del MODELO y el número de SERIE
del motor para el cual se solicitan las piezas.
Usar siempre los números de pieza correctos
indicados en la lista de piezas.
