minnkota.johnsonoutdoors.com | 69 ©2023 Johnson Outdoors Marine Electronics, Inc.
PARTS DIAGRAM & PARTS LIST
Assembly Part # Description Notes Quantity
J 2441050 MTR ASY 90/115# NS SW WHT 60" *60”* *SALTWATER WHITE* 1
K 2441051 MTR ASY 90/115# NS SW WHT 72" *72”* *SALTWATER WHITE* 1
L 2441052 MTR ASY 90/115# NS SW WHT 87" *87”* *SALTWATER WHITE* 1
M 2441053 MTR ASY 90/115# NS SW WHT 100" *100”* *SALTWATER WHITE* 1
N 2441055 MTR ASY 90/115# NS SW BLK 60" *60"* *SALTWATER BLACK* 1
P 2441056 MTR ASY 90/115# NS SW BLK 72" *72"* *SALTWATER BLACK* 1
Q 2441057 MTR ASY 90/115# NS SW BLK 87" *87"* *SALTWATER BLACK* 1
R 2441058 MTR ASY 90/115# NS SW BLK 100" *100"* *SALTWATER BLACK* 1
S 2991065 SHAFT ASM 60" U2,T3 *60"* *SHAFT* *60”* 1
T 2991051 SHAFT ASM 72"INST,RT/T3 *72"* *SHAFT* *72”* 1
U 2991052 SHAFT ASM 87"INST,RT/T3 *87"* *SHAFT* *87”* 1
V 2991053 SHAFT ASM 100"INS,RT/T3 *100"* *SHAFT* *100”* 1
W 2992604 BAG ASSM, PROP HARDWARE 1
Item Part # Description Notes Quantity
72 880-032 SEAL-FRONT, BL MOTORS 1
74
✖
STATOR ASSEMBLY 1
76
✖
ROTOR ASSEMBLY 1
78
✖
WASHER BEARING 2
80
✖
BALL BEARING 2
82
✖
REAR ENDBELL, SW WHT PAINT *SALTWATER WHITE* 1
✖
REAR ENDBELL, SW PAINT BLACK *SALTWATER BLACK* 1
84
✖
CENTER HSG, SW WHT PAINT *SALTWATER WHITE* 1
✖
CENTER HSG, SW BLACK PAINT *SALTWATER BLACK* 1
86
✖
SEAL 2
88
✖
PAPER TUBE - SEAL BORE 1
90
✖
O-RING 1
92
✖
O-RING 1
94
✖
WASHER-WAVE 1
96
195-032 CABLE-COM 22GA TWST PAIR 76.25 *60”* 1
195-033 CABLE-COM 22GA TWST PAIR 87.63 *72”* 1
195-034 CABLE-COM 22G TWST PAIR 102.63 *87”* 1
195-035 CABLE-COM 22G TWST PAIR 111.38 *100”* 1
98
640-472 LEADWIRE RED 8 AWG 78.75" *60”* 1
640-483 LEADWIRE RED 6 AWG 90.13" *72”* 1
640-484 LEADWIRE RED 6 AWG 105.13" *87”* 1
640-485 LEADWIRE RED 6 AWG 118.13" *100”* 1
24/36 Volt 90/115lb Thrust Motor Parts List
p Not shown on Parts Diagram.
✖ This part is included in an assembly and cannot be ordered individually.
