PARTS DIAGRAM & PARTS LIST
Item Part # Description Notes Quantity
100
640-422 LEADWIRE BLK 8 AWG 78.75" *60”* 1
640-433 LEADWIRE BLK 6 AWG 90.13" *72”* 1
640-434 LEADWIRE BLK 6 AWG 105.13" *87”* 1
640-435 LEADWIRE BLK 6 AWG 118.13" *100”* 1
102 2994130 INVERTER ASM, 24/36V, BL 1
104 979-031 STRAIN RELIEF,BTM MACH WIRETAB 1
106 830-118 SCREW-DBL SEM M5X.8MMX60MM 3
108 2307318 FERRITE BEAD, BL 1
110 9953310 TIE WRAP-8" 1
112 830-120 SCREW-M4X .7X8 PPH ZPS 5
114 979-022 STRAIN RELIEF, TOP CAST 1
116 830-121 SCREW-M5 X .8X18 PPH ZPS 2
118 701-010 O-RING, SCREW 4
120 830-115 SCREW-FRONT, TOP, COATED, BL MTR 2
122 830-116 SCREW-FRONT, BTM COATED, BL MTR 2
124 880-042 SEAL-WIRE, BL MTR, PLAIN END 1
126
✖
TUBE-1CM, BLK 60", 1.5 X .875 *60”* 1
✖
TUBE-5CM, BLK 72", 1.5 X .75 *72”* 1
✖
TUBE-5CM, BLK 87", 1.5 X .75 *87”* 1
✖
TUBE-5CM, BLK 100", 1.5 X .75 *100”* 1
128
✖
PLUG, COMP SHAFT, PAINTED 1
130 2294630 O-RING, 226, 70 SHORE A 1
132
✖
SEAL-TOP SHAFT, BRUSHLESS, CLR 1
134
✖
SEAL-LWR SHAFT, BRUSHLESS, CLR 1
136 2206452 PLATE, CLAMP, PAINTED. BELT 1
138 830-013 SCREW-M5 X .8 FSHCS SS CTD 6
140 2262659 PIN-DRIVE 1" X 3/16" SS 17-4 1
142 2321170 PROP, POWER REAMED 1
144 2091701 WASHER-PROP (LARGE) MAX101 1
146 2093101 NUT-PROP,NYLOC,LG,MX101 3/8 SS 1
p
2005764 DECAL, SERIAL NO, BL LWR UNT 1
148
421-168 FRONT ENDBELL, PLAIN, SW WHT PNT *SALTWATER WHITE* 1
421-169 FRONT ENDBELL, PLAIN, SW BLACK *SALTWATER BLACK* 1
p Not shown on Parts Diagram.
✖ This part is included in an assembly and cannot be ordered individually.
