MINN KOTA RIPTIDE TERROVA - Page 10

10 | minnkotamotors.com
©2022 Johnson Outdoors Marine Electronics, Inc.
INSTALLING THE RIPTIDE TERROVA
Deck of BoatDeck of Boat
KeelKeel
Power CablesPower Cables
Right SideplateRight Sideplate
Left SideplateLeft Sideplate
Base ExtrusionBase Extrusion
2c
2d
2
WARNING
Make sure the motor is mounted on a level surface and is not
connected to a power source.
4
3
c. Remove the Right Sideplate.
d. Swing the Left Sideplate out and away from the
Base Extrusion.
e. Make sure that the Power Cables from the battery
are disconnected, or that the breaker,
if equipped, is "o."
f. Place the mount as close to the centerline or keel
of the boat as possible. The motor can be installed
on either the Port or Starboard side of the boat
based on personal preference. Check placement
with the motor in the stowed and deployed positions.
Review the mounting considerations at the
beginning of the installation.
