STOWING AND DEPLOYING THE MOTOR
This motor is equipped with a Push-to-Test Battery Meter. The
LED located on the Indicator Panel on the Mount of the motor.
The Battery Meter provides an accurate display of the remaining
charge in the battery. It is only accurate when the motor is o.
The meter reads as follows:
• One light indicates recharge.
• Two lights indicate low charge.
• Three lights indicate good charge.
• Four lights indicate full charge.
PUSH-TO-TEST BATTERY METER
Indicator Indicator
PanelPanel
Push-to-Test Push-to-Test
Battery MeterBattery Meter
NOTICE: No lights indicates no battery connection or an
incorrect battery connection.
