Assembly Part # Description Notes Quantity
M 2774178 t MOTOR KIT, iPLT 1.6 RT TERROVA *i-PILOT RECEIVER* 1
N 2774179 Â MOTOR KIT, iPLT 3.0 RT TERROVA *i-PILOT LINK RECEIVER* 1
V 2994075
t REMOTE ASSY, IPILOT 1.6 1
W 2994076 Â REMOTE ASSY, IPILOT LINK *LINK ONLY* 1
X 2770235
t COVER KIT, iPLT 1.6 RT TERROVA *i-PILOT COVER & DECALS ONLY* 1
Y 2770236 Â COVER KIT, iPLT 3.0 RT TERROVA *i-PILOT LINK COVER & DECALS ONLY* 1
Item Part # Description Notes Quantity
p
✖
SEAL,BUNG LOWER 1
p
✖
SEAL,BUNG UPPER,SW 1
2 2994097 l TRANSMITTER ASY,TRRV CPLT *COPILOT* 1
4 2374197 l PCB ASY COPLT REC. TERROVA *COPILOT* 1
6
2395551
t DECAL, COVER, RT, TERROVA 55 *55LB THRUST* 1
2395555
t DECAL, COVER, RT, TERROVA 80 *80LB THRUST* 1
2325635
t DECAL, COVER, RT, TERROVA 112 *112LB THRUST* 1
p
2256300 TIE WRAP-5.5" BLACK 2
8 2292501 CONTROL BOX, SW ST 1
10 2263406 SCREW-#10-24 X 2” SS PPH 1
12 2333101 NUT-HEX #10-24 UNC-2B NYL SS 1
14 2224707 INSERT-PLUG 1
16 2372103 SCREW. #6 x 3/8 PLASTITE 2
18 2325633 l DECAL COVER, RT, T2 80 1
p
9950433 TIE WRAP-4" BLACK 2
20 2305402 SHRINK TUBE-.374 OD X 2.25" 2
22 2290218 COVER,CTRL BOX, RT PD PRINTED PD V3, RT/V3 MK LOGO *COPILOT* 80LB THRUST* 1
24 2292501 CONTROL BOX, SW ST 1
26
2395546
t DECAL, DOMED IPILOT SW *iPILOT* 1
2395548 Â DECAL, DOMED, iPILOT LINK SW *iPILOT LINK* 1
28 2372100 SCREW-#8-18 X 5/8 THD (SS) 7
30 2390800
t LANYARD, REMOTE W/ CARABINER 1
32 2395900 Â ADAPTER, USB DC POWER *LINK ONLY* 1
34 2373241 Â CABLE, USB REMOTE CHARGER *LINK ONLY* 1
36 490389-1 Â CABLE, ETHERNET, 30' *LINK ONLY* 1
38 2996400
t HEADING SENSOR ASSEMBLY *SELECT MODELS ONLY* 1
p
2397106 t MANUAL, QUICK REF., IPILOT 1.6 1
p
2397107 Â MANUAL, QUICK REF., IPILOT LINK 3.0 1
Control Head Parts List
l Only available with models factory installed with CoPilot.
p Not shown on Parts Diagram.
✖ This part is included in an assembly and cannot be ordered individually.
t Only available with models factory installed with i-Pilot.
 Only available with models factory installed with i-Pilot Link.
