MINN KOTA RIPTIDE TERROVA - Page 43

Assembly Part # Description Notes Quantity
A 2779034 MTR/TUBE ASM 55# 54" RT TRV BT *MOTOR & TUBE* *54* *3.625* 1
Q 2779036 MTR/TUBE ASm 55# 60" *MOTOR & TUBE* *60* *3.625* *EUROPE ONLY* 1
Z 2779307 CTR HSG, CB, 55#, SW 60" *UP TO 60"* *TUBE* *3.625* 1
BB 1378131 PROP IND 2091160 WDLS WDG II *3.625* *55LB THRUST* 1
S 2888460 SEAL & O-RING KIT *55LB THRUST* *3.625* 1
Item Part # Description Notes Quantity
50
✖
TUBE-COMP,WHT,54",1/4" WALL,T2 *54”* *55 LBS* 1
✖
TUBE-COMP,WHT,60",1/4" WALL,T2 *iPILOT* *60”* *55 LBS* 1
52 2092600 PIN-DRIVE 1" X 3/8" S/S *55LB THRUST* *3.625* 1
54 2151726 WASHER-5/16 STD (S/S) *55LB THRUST* *3.625* 1
56 2053101 NUT-PROP,NYLOC(MED) 5/16-24 SS *55LB THRUST* *3.625* 1
58 2091161 PROP-WW2 3 5/8" MACHINED *55LB THRUST* *3.625* 1
60 975-040 SPRING - TORSION *3.625* *55LB THRUST* 2
62
640-151 LEADWIRE RED 10 AWG 70.375 GPT *54”* *55 LBS* 1
640-156 LEADWIRE RED 10 AWG 76.375 *iPILOT* * 60”* *55 LBS* *M* 1
64
640-023 LEADWIRE BLK 10 AWG 69" GPT *54”* *55 LBS* 1
640-056 LEADWIRE BLK 10 AMP 75” GPT *iPILOT* *60”* *55 LBS* *M* 1
66 188-036 BRUSH ASSEMBLY *3.625* *55LB THRUST* 2
68 738-036 BRUSH PLATE WITH HOLDER 3.625 *3.625* *55LB THURST* 1
70 725-050 PAPER TUBE - BRUSH RETENTION *3.625* *55LB THRUST* 1
72 2-100-146 ARM ASY 12V 3.62 55#CB/LS *55LB THRUST* *3.625* 1
74
✖
CTR HSG ASY 3.6 SW/CB/W-MG *55LB THRUST* *3.625* 1
76 421-350 HSG BRSH END 3.62 SW CB/WHITE *55LB THRUST* *3.625* 1
78 2-400-337 PLAIN END HSG ASY 3.6 TX/W *55LB THRUST* *3.625* 1
80 337-036 GASKET *55LB THRUST* *3.625* 1
82 701-008 O-RING *55LB THRUST* *3.625* 2
84 701-081 O-RING *55LB THRUST* *3.625* 1
86 830-007 SCREW, # 8-32 *55LB THRUST* *3.625* 2
88 830-108 THRU BOLT 10-32 X 9.205 COATED *55LB THRUST* *3.625* 2
90 990-067 WASHER - STEEL THRUST *55LB THRUST* *3.625* 1
92 990-070 WASHER - NYLATRON *55LB THRUST* *3.625* 1
94 788-015 RETAINING RING *3.625* 1
96 880-003 SEAL 1
98 880-006 SEAL WITH SHIELD 1
100 144-049 BEARING-FLANGE 1
102 725-035 PAPER TUBE - SEAL BORE 1
12 Volt 3.626” Motor Parts List
l Only available with models factory installed with CoPilot.
p Not shown on Parts Diagram.
✖ This part is included in an assembly and cannot be ordered individually.
t Only available with models factory installed with i-Pilot.
 Only available with models factory installed with i-Pilot Link.
minnkotamotors.com | 43
©2022 Johnson Outdoors Marine Electronics, Inc.
PARTS DIAGRAM & PARTS LIST
