Item Part # Description Notes Quantity
328 2321702 WASHER-FLAT .375 NYLON 2
330 2263011 E-RING 3/8 DIA. SHAFT 2
332 2322702 SPRING, LATCH PIN SS 2
334 2323410 SCREW-#8-32 X .75 SHCS SS 1
336 2327310 BUSHING, PIVOT PIN 2
338 2321500 DEPTH COLLAR 1.3 1
340 2321702 WASHER-FLAT .375 NYLON 1
342 2260906 KNOB-SOFT GRIP,HG/DR,SS 1
344 2053422 SCREW-M3-.5 X 10 PPH, ZPS 4
346 2327314 BUSHING, PRO STEERING SW 2
348 2320321 WIRE EXTENSION, 112" THRUST MOTOR 1
350 2321523 COLLAR, FRONT, LIFT ASSIST 1
352 2321527 COLLAR, BACK, LIFT ASSIST 1
354 3393450 SCREW #6-19 x .75 4
p
2325502 DECAL, STOW / DEPLOY, T2 1
l Only available with models factory installed with CoPilot.
p Not shown on Parts Diagram.
✖ This part is included in an assembly and cannot be ordered individually.
t Only available with models factory installed with i-Pilot.
 Only available with models factory installed with i-Pilot Link.
