(2720)A 31
Related adjustment and required setting items
When each adjustment or setting is operated, be sure to follow the related adjustment and setting items
listed blow.
Number : Related adjustment items. Adjust and set in order of the number.
× : Related adjustment items. However, these items mean not to adjust the adjustment order is
different (the adjustment should be completed).
None : Unrelated adjustment and setting items (possible to adjust and set solely).
Related adjustment/
setup necesaary items
Adjustment/
Setup items
Adj. For CCD perspective (CCD AORI)
Adj. for sensitivity (GAIN)
Adj. for center part of CCD (CCD CENTER)
Frequency adj. for camera shaking
(ACT DRV FREQ)
Servo adj. for camera shaking
(ACT DRV FREQ)
Gyro adj. for camera shaking
(GYRO OFFSET)
Shutter adj. (SHUTTER)
Defective pixel adj. (DEFECT PIXEL)
Flash GN adj. (FL GNo)
White balance adj. (WB)
Focus adj. (FCS INF POS)
Manual focus PI adj. (MF PI)
Adj. for camera shaking
compensation (SHAKE OFFSET)
DESTINATION Setting (DESTINATION)
Setting date and time (TOD)
Adj. For CCD perspective (CCD AORI)
12 3 4 5 678910 11 12
Adj. for sensitivity (GAIN) × 1 2 3 4 56789 10 11
Adj. for center part of CCD (CCD CENTER)
× 1 2 3 45678 9 10
Frequency adj. for camera shaking
(ACT DRV FRE
)
× × 1 2 34567 8 9
Servo adj. for camera shaking
(SERVO GAIN)
× × × 1 23456 7 8
Gyro adj. for camera shaking
(GYRO OFFSET)
× × × × 12345 6 7
Shutter adj. (SHUTTER)
××××× 1234 5 6
Defective pixel adj. (DEFECT PIXEL)
××××× 123 4 5
Flash GN adj. (FL GNo) × × × × × × 1 2 3 4
White balance adj. (WB) × × × × × × × 1 2 3
Focus adj. (FCS INF POS) × × × × × × × × 1 2
Manual focus PI adj. (MF PI)
Adj. for camera shaking
com
ensation (SHAKE OFFSET)
× × × × × ××××× 1
DESTINATION Setting (DESTINATION)
Setting date and time (TOD) × × × × × × × × × × ×
