Minolta A2 User Manual

18 (2720)A
REPAIR GUIDE
G
F
F
G
1
3
4
5
6
7
8
9
9
10
11
12
13
14
15
16
17
18
19
20
20
21
22
2
■■
■■
■
Fig. 1, 2, 3Fig. 1, 2, 3
Fig. 1, 2, 3Fig. 1, 2, 3
Fig. 1, 2, 3
■■
■■
■
Fig. 4Fig. 4
Fig. 4Fig. 4
Fig. 4
4. Disassembly of the compl PWB SY-1/ST-1/PW-1/TB-1/SY-2/DM-1
Disassemble it in order of step 1 to 22.

Minolta A2 Specifications

General

Sensor Type	CCD
Optical Zoom	7x
Display Size	1.8 inches
ISO Sensitivity	64 - 800
Image Stabilization	No
Max Resolution	3264 x 2448
Image Ratio w:h	4:3
Sensor Size	2/3" (8.8 x 6.6 mm)
Maximum Aperture	F2.8 - F3.5
Storage Types	CompactFlash (Type I or II), Microdrive
Viewfinder	Electronic
Resolution	8 megapixels
Lens Focal Length	28 - 200 mm
Battery	NP-400 Lithium-Ion rechargeable battery
Shutter Speed	30 - 1/4000 sec
