(2720)A 33
Starting up the 2720 adjustment program (in the adjustment mode).
Outline
Connect the camera and PC with USB-500 and start up the camera in the "adjustment mode."
"Adjustment mode" means the condition of that the camera can contact with the 2720 adjustment program
in the PC.
Required equipment
PC with preinstalled the 2720 adjustment program
AC-1L/AC-11
USB-500 (USB cable)
* Use the AC adapter (AC-1L/AC-11) not batteries when adjusting.
Starting up the 2720 adjustment program (in the adjustment mode).
1. Starting up the 2720 adjustment program, "#2720rpAdj.exe."
2. Turn the recording mode and the dial to the "M mode."
3. Press "Function button," "Digital effect button" and "AEL button" together and turn the main switch
on.
When the self-timer lamp turns on, the camera starts up in the "adjustment mode."
4. Follow the direction of the 2720 adjustment program, "Please connect a camera and click START!"
Connect the camera and PC with USB-500, and click "START" after confirming the USB connection.
* When adjusting CCD perspective (P.37) (when starting up without the assy cabi back)
1. Remove the cabinet top (1124) and the assy cabi back (0160).
2. Remove the control back unit (2782-0458) of the assy cabi back.
3. Connect the connector of the control back unit.
4. Connect the connector of the control top unit (0428) from the cabinet top (1124).
5. Start up in the way mentioned above of starting up the 2720 adjustment program (in the adjustment
mode).
Quitting the 2720 adjusting program
1. Click "END" of the 2720 adjustment program.
2. Remove the AC adapter.
