(2720)A 47
REPAIR GUIDE
Adjustment of the manual focus PI (MF PI)
Required equipment
PC with preinstalled the 2720 adjustment program
USB-500 (USB cable)
AC-1L/AC-11
Preparation of the adjustment
1. Start up the 2720 adjustment program.
2. Connect the camera and PC with USB-500, and click "START" after confirming the USB connection.
Procedure of the adjustment
1. Click "MF PI" of the adjustment menu.
2. Follow the message, "Please turn a focal ring with half-rotation/sec." and turn the focus ring by half.
The adjustment is automatically started.
2. The adjustment is completed when "OK" is displayed on the adjustment menu.

Minolta A2 Specifications

General

Sensor Type	CCD
Optical Zoom	7x
Display Size	1.8 inches
ISO Sensitivity	64 - 800
Image Stabilization	No
Max Resolution	3264 x 2448
Image Ratio w:h	4:3
Sensor Size	2/3" (8.8 x 6.6 mm)
Maximum Aperture	F2.8 - F3.5
Storage Types	CompactFlash (Type I or II), Microdrive
Viewfinder	Electronic
Resolution	8 megapixels
Lens Focal Length	28 - 200 mm
Battery	NP-400 Lithium-Ion rechargeable battery
Shutter Speed	30 - 1/4000 sec
