6
1306246-W2-A
Specications
Plumbing Supply
Supply Source Mains pressure cold water only
Minimum Dynamic Pressure*
50 kPa (0.5 bar)
(100 kPa (1 bar) BEAB Care)
Maximum Dynamic Pressure 500 kPa (5.0 bar)
Maximum Static Pressure 1000 kPa (10 bar)
Minimum Static Pressure** 20 kPa (0.2 bar)
Maximum Inlet Temperature 30°C (20°C BEAB Care)
Minimum Inlet Temperature 2°C (5°C BEAB Care)
Inlet Connection ½" BSP male & 15 mm compression
tting.
Outlet Connection ½" BSP male fitting
Electrical Supply
Nominal Rating at 230 V 8.0 kW 9.0 kW
Nominal Rating at 240 V 8.7 kW 9.8 kW
Supply Fuse/Circuit Breaker
8.7 kW 40 Amps
9.8 kW 45 Amps
Residual Current Device RCD 30 mA
Supply Cable
No larger than 16 mm²
Note: Refer to current IEE regulations and
BS 7671 to determine minimum cable size.
Isolation Switch
45 Amp Double pole, with 3 mm contact
separation.
Maximum Ambient Temperature 30°C
Minimum Ambient Temperature 2°C
Dimensions (shower unit)
Height 408 mm
Width 187 mm
Depth Flex : 112 mm , Standard : 105mm
* Recommended dynamic pressure of 100 kPa (1.0 bar) for full ow performance.
** Static pressure must never fall below 20 kPa (0.2 bar) when other draw offs are in use,
e.g. ushing toilet. This is the minimum pressure required to keep the ow valve closed.
