35
Filter Cap
Filter Plug
‘O’ Seal
Filter
Inlet Filters
The Inlet Filters should be checked and cleaned as necessary every 12 months.
Note! The Inlet Filters must not be removed except for cleaning. If the unit is operated
without the Inlet Filters fi tted, the warranty on the product will be void.
Exposed Models
1. Isolate the hot and cold water supplies and operate the Flow Control Lever to
drain any residual water.
2. Carefully remove the Filter Caps and unscrew the Filter Plugs with the ‘O Key’
(supplied) or a 12 mm hexagonal wrench. Remove the Filters.
3. Clean the Filters under a jet of water to remove any lodged particles.
4. Refi t the Filters and tighten the Filter Plugs.
Note! Make sure that the ‘O’ seal is fi tted correctly and undamaged.
5. Turn on the hot and cold water supplies and check for leaks.
6. Refi t the Filter Caps.
