37
Caution! The mixed water temperature at the terminal fi tting should never
exceed 46°C.
Units operating outside these conditions cannot be guaranteed to operate as
Type 2 valves.
Application
The approved designations for Type 2 valves are as follows:
The permitted application details are:
†
Mixed water temperature at discharge point.
In order to achieve the safe water temperatures expected of a Type 2 valve, it is
essential that the unit is used only for the applications covered by its approved
designations, with the appropriate water supply pressures and temperatures. It must
be commissioned, maintained and serviced in accordance with the recommendations
contained in this guide. Refer to section “Maintenance, In-Service Tests” for
the in-service test frequency that must be used as a minimum guide in Type 2
installations.
Supply Conditions
For applications where a Type 2 valve is required, the supply conditions must comply
with the values in the table below. Note that both hot and cold supply pressures must
lie within the same pressure range.
Model Designation Code
HP-S / LP-S
Mira Select
Designation
Operating
Pressure Range
Application
Mixed Water
Temperature
†
°C
Shower
Shower
41 °C maximum
41 °C maximum
High Pressure
Low Pressure
HP-S
LP-S
TYPE 2 VALVES
Cold Supply Temperature -
o
C
Supply Conditions
High Pressure
HP
Low Pressure
LP
Maximum Static Pressure - bar
Maintained Pressure, Hot and Cold - bar
Hot Supply Temperature -
o
C
10
1 to 5
55 to 65
< 25
10
0.2 to 1
55 to 65
≤ 25
