The Buzzer and LED Indicators
3.2.3 Property and Building Safety Circuit Indicators
This operation applies to initiating circuits configured as property and building safety circuits.
The following table summarizes the indications in response to different events:
3.2.4 Trouble-only Circuit Indicators
This operation applies to initiating circuits configured as Trouble-Only Circuits. The following
table summarizes the indications in response to different events:
Table 3 Property and Building Safety Circuit Indicators
Event Circuit Status LED Configuration
Circuit Active Steady (amber)
Property and Building
Safety
Activated circuit reconnected
Fast flash rate (red) for 5
seconds to indicate a
pending alarm
Event Circuit Trouble LED Configuration
Open circuit (Class B)
Flashes at the trouble rate
(amber)
Property and Building
Safety
Open circuit or Style D/Class A trouble
Flashes at the trouble rate
(amber)
Disconnected (Style D/Class A)
Flashes at the trouble rate
(amber)
Circuit Active OFF
Table 4 Trouble-Only Circuit Indicators
Event Circuit Trouble LED Configuration
Open circuit (Class B)
Flashes at the trouble rate
(amber)
Trouble Only
Open circuit or Style D/Class A trouble
Flashes at the trouble rate
(amber)
Disconnected (Style D/Class A)
Flashes at the trouble rate
(amber)
Short Circuit
Flashes at the trouble rate
(amber)
