15 (20)
Main Display Buttons
4.6 AUXILIARY DISCONNECT Button
4.7 LAMP TEST Button
4.8 ALM/SUP/TBL/BLDG AUDIBLE SIL Button (or MENU for single
stage systems)
Pressing the AUXILIARY DISCONNECT button activates the auxiliary disconnect function.
Pressing the button again de-activates this function.
Pressing and holding the LAMP TEST button causes all front panel LEDs to illuminate and
sounds the buzzer. Use this button to test that all LEDs in the main display are working. If
you hold the LAMP TEST button for more than ten seconds, the COMMON TROUBLE
LED will illuminate.
If the Panel is configured as a two-stage system, press the ALM/SUP/TBL/BLDG
AUDIBLE SIL (buzzer silence) button to silence the buzzer. The buzzer resounds if there is
a subsequent event. Pressing the button when the buzzer is not sounding has no effect.
If the Panel is configured as a single stage system, press the MENU button to select the
command menu when a CFG-300 Service Tool with LCD is connected. Otherwise, this
button has no effect.
ALM/SUP/TBL/BLDG
AUDIBLE SIL
