Configuration with the CFG-300 LCD Service Tool
Command Menu/FA-300 Config/Features/
7. AUXILIARY DISCONNECT
disconnects Alarm Relay and
Supervisory Relay
[ ] ENABLE
[X] DISABLE->Default
"Aux Disconnect"
disconnects alarm
relay
If enabled, the Common Alarm
Relay and the Common
Supervisory Relay, in addition to
the Auxiliary Alarm Relay, are
disconnected when you press
AUXILIARY DISCONNECT (see
9.4.6 AUXILIARY DISCONNECT
Button on page 48). The PR-300
does not transmit a supervisory
or alarm event.
If disabled, pressing AUXILIARY
DISCONNECT has no effect on
the Common Alarm Relay, the
Common Supervisory Relay, and
the PR-300.
Command Menu/FA-300 Config/Features/
8.Auto Signal Silence Timer
[X] DISABLE->Default
[ ] 5 Min
[ ] 10 Min
[ ] 15 Min
[ ] 20 Min
[ ] 30 Min
Signal silence Timer
Use this menu to determine the
time period for which the
indicating circuits sound before
they are automatically silenced.
For UL installations, disable the
Auto Signal Silence Timer.
Command Menu/FA-300 Config/Features/
9. Number of Remote
Annunciators or smart relays
[X] NONE->Default
[ ] 1
[ ] 2
[ ] 3
[ ] 4
[ ] 5
[ ] 6
Remote annunciators
Use this menu to select the
number of remote annunciators.
Any combination of remote
annunciators or smart relays can
be used as long as the total
number does not exceed 6. The
annunciators’ addresses should
be without gaps and in sequence.
Command Menu/FA-300 Config/Features/
10.Silence Alarm transmit
[X] DISABLE->Default
[ ] ENABLE
Alarm transmit affected
by signal silence
If disabled, the SIGNAL
SILENCE button does not silence
the Auxiliary Alarm Relay, but it
does silence the indicating
circuits. If enabled, the SIGNAL
SILENCE button silences the
Auxiliary Alarm Relay and the
indicating circuits. See 9.4.2
SIGNAL SILENCE Button on
page 48.
Command Menu/FA-300 Config/Features/
11.AC power fail delay timer
[X] NONE ->Default
[ ] 1 HRS
[ ] 2 HRS
[ ] 3 HRS
Use this menu to delay the AC
power fail trouble for the
programmed time period. If
disabled, the AC power fail is
reported right away.
Table 14 Feature Config menu
Feature Default
Name in the
FA-300
Configuration Utility
Description
Aux Dis,Dis Alm&Spv
[X] DISABLE
Auto Sig-Sil. Timer
[X] DISABLE
No. of Remote Annun.
[X] NONE
Alm. Xmit-Sil.
[X] DISABLE
AC Pwr Fail Dly Tmr.
[X] NONE
