66
Configuration with the CFG-300 LCD Service Tool
Command Menu/FA-300 Config/Features/
12.Common Supervisory Relay
[ ] ENABLE ->Default
[X] DISABLE
Supervisory relay used
as alarm relay
If enabled, the Common
Supervisory Relay behaves as a
common alarm relay. If disabled,
it behaves as a common
supervisory relay.
Command Menu/FA-300 Config/Features/
13.Signal Isolators
[ ] ENABLE
[X] DISABLE->Default
Isolators on signal
circuits
Enable this function only when
suite isolators are used (Canada
only).
Command Menu/FA-300 Config/Features/
14.Strobe Type
[X] NORMAL ->Default
[ ] MIRCOM
[ ] FARADY
[ ] WHEELOCK
[ ] GENTEX
[ ] SYSTEM SENSOR
Strobe
Use this menu to select the
manufacturer of the strobes used
in the system. The selection is
system-wide and applies to all
indicating circuits configured as
strobes. For NORMAL strobes
there is no synchronization, while
other strobes are synchronized
and use manufacturer’s protocol
to synchronize the strobes.
Command Menu/FA-300 Config/Features/
15.Signal Rate
[X] TEMPORAL->Default
[ ] CONTINOUS
[ ] MARCH TIME
[ ] CALIFORNIA
Signal rate
Use this menu to set the rate at
which the indicating circuits
sound.
Command Menu/FA-300 Config/Features/
16. Active EOL
[X] DISABLE->Default
[ ] NO
Active end-of-line
Enable this function if using an
Active End-of-Line resistor.
Enable this function if you are
using the ICAC-306 (the ICAC-
306 has built in Active End-of-
Line resistors).
Command Menu/FA-300 Config/Features/
17. Two-stage Operation
[X] DISABLE->Default
[ ] ENABLE
Second stage
Use this menu to allow the
system to perform a two-stage
operation. This selection also
sets the Auto General Timer to 5
minutes.
The user should always either
disable the Auto Signal Silence
Timer or set it to be greater than
the Auto General Alarm Timer.
Table 14 Feature Config menu
Feature Default
Name in the
FA-300
Configuration Utility
Description
Common Supv. Relay
[X] DISABLE
Sig-Sil. Isolator
[X] DISABLE
Two Stage Operation
[X] DISABLE
To Next Page
