Instructions For Use – neXus Ultrasonic Surgical Aspirator
Doc #: 100-10-1000 rev A p 23
5.
System Overview
5.1.
Principle of Operation
The neXus Ultrasonic Surgical Aspirator System is comprised of a generator which converts mains voltage and frequency to a
22.5 kHz (Standard Handpiece) or 23.0 kHz (SonaStar Short & Long Handpiece) electrical signal depending upon the handpiece
and accessories that are connected to the console. The generator feeds the electric signal to a piezoelectric transducer
comprised of a ceramic crystal stack in the handpiece. The crystals vibrate at the output frequency translating the electrical
energy into mechanical vibration. A titanium horn amplifies the vibration and transmits the amplified vibration to a titanium
probe tip. The titanium probe tip is the applied part that comes into contact with patient tissue. An integrated irrigation pump
delivers an irrigation solution to the surgical site. An integrated aspiration system removes the fragmented, emulsified
material and waste liquids from the area. Accessories include various horn/probe tips, irrigation & aspiration tubing sets,
wrenches, and cleaning brushes.
5.2.
Reusable, Non-Sterile Components
Table 5.2: Reusable System Components
Components and quantities included with the system may change over time, please check with your Misonix
representative for the most current configuration.
For the cleaning and sanitization of the console, footswitch, and cart Misonix recommends the use of EPA certified
CaviWipes® or equivalent quaternary ammonium compound surface disinfectant wipe. Please follow
manufacturer’s instructions for surface cleaning and disinfection of hard non-porous surfaces, including, without
limitation, the use of personal Protection Equipment (PPE) for Bloodborne Pathogens. Dispose of the used wipes in
accordance with local regulations regarding the disposal of biological hazardous wipes.
Refer to the handpiece IFU’s for cleaning and sterilization procedures for the reusable handpiece parts and
accessories.
CAUTION Only external surfaces of the console should be cleaned. Do not attempt to remove any panels in
order to clean or disinfect internal surfaces.
CAUTION Do not immerse ultrasonic console, handpiece, irrigation pump or electric cables. These items are
not sealed against liquids and damage to equipment will result.
5.3.
Single Use, Sterile Components
There are a variety of single-use sterile components for the neXus Ultrasonic System. The components include
various tips, tubing, and other accessories. Ultrasonic tips & tubing are supplied in a combined, sterile package,
and are for single use only. Please ask your Misonix representative for the latest catalog of available products.
neXus console; including an IV pole, power cord, peristaltic pump, filter, and instructions for use
neXus Handpiece Kit (i.e. Standard Handpiece for Bonescalpel or SonicOne O.R. Applications)
neXus Handpiece Kit (i.e. Long or Short Handpiece for Sonastar Applications)
neXus Wireless Footswitch
