Instruction Manual MIT-SCAN-T3 Version 02/2021
Page 16
2.1.2 Data exchange via USB interface
With USB interface, measurement data can be exchanged between
device and PC. Connect a USB flash drive to device and opening the
Main Menu starts the automatic synchronization of data between MIT-
SCAN-T3 and USB flash drive. Remove the USB flash drive after having
exchanged data successfully. Measurement data is stored in file “MIT-
SCAN-T3_ device number .T3”. Use MIT Project Software to import this
file into a form sheet for further processing.
2.1.3 Headphone interface
This interface provides a connection for headphone with 3.5 mm audio
jack. During a reflector search, acoustic signals are emitted depending
on the received signal. Using headphones will make it easier to locate
reflectors in high-noise environments.
2.1.4 Bluetooth interface
Bluetooth module allows wireless connection to mobile Apps.
