1.2 Reflectors
Name
Description
Material
thickness
Max.
depth
4
AL RO 07
AL RO 12
AL RO 30
Circular plate
Diameter: 7, 12 and 30 cm
Material: Aluminum
1.0 mm
1.0 mm
0.5 mm
12 cm
18 cm
35 cm
AL RE 30x70
AL RE 30x100
Rectangle (foil/sheet)
Width x Length 30 x 70/100 cm
Material: Aluminum
0.1/0.3 mm
0.1/0.3 mm
50 cm
50 cm
ST RO 12
ST RO 30
Circular plate
Diameter: 12 and 30 cm
Material: Steel
1.00 mm
0.65 mm
18 cm
35 cm
Table 1 Description of the available antipoles
4
Information about the measuring range: see Table 2 Measuring range of
reflectors
Special note:
 Devices are calibrated and
validated for use with
specified reflectors.
 Reflectors must be of
verified quality.
 MIT circular reflectors
carry MIT´s logo.
 The packaging comes with
quality seal (s. Fig. 5) and
label showing a batch
number.
Fig. 5 Quality seal
