Instruction Manual MIT-SCAN-T3 Version 02/2021
measurement. By means of the signal characteristics, the reflector is
determined and the layer thickness calculated.
In the results´ representation, the identified reflector is displayed in
addition to layer thickness. The user is recommended to conduct a
plausibility check of both: the identified reflector as well as the
relatedly displayed layer thickness.
The automatic circular plate recognition can identify the following
reflectors (details in Table 1, p. 9):
