N/B Maintenance
N/B Maintenance
The ICS952001 is part of a whole new line of ICS clock generators and buffers called TCH™ (Timing
Control Hub). ICS is the first to introduce a whole product line which offers full programmability and
flexibility on a single clock device. Employing the use of a serially programmable I2C interface, this device
can adjust the output clocks by configuring the frequency setting, the output divider ratios, selecting the ideal
spread percentage, the output skew, the output strength, and enabling/disabling each individual output clock.
TCH also incorporates ICS's Watchdog Timer technology and a reset feature to provide a safe setting under
unstable system conditions. M/N control can configure output frequency with resolution up to 0.1MHz
increment.
Recommended Application:
2 - Pairs of differential CPUCLKs @ 3.3V
1 - SDRAM @ 3.3V
8 - PCI @3.3V
2 - AGP @ 3.3V
2 - ZCLKs @ 3.3V
1 - 48MHz, @3.3V fixed
1 - 24/48MHz, @3.3V selectable by I
2
C
3 - REF @3.3V, 14.318MHz
SiS645/650 style chipsets
Output features:
