N/B Maintenance
N/B Maintenance
1.2.10 System Flash Memory (BIOS)
2 M bit Flash memory
Flashed by 5V only
User can upgrade the system BIOS in the future just running flash program
1.2.11 Memory System
JEDEC-standard 200-pin, small-outline, dual in-line memory module (SODIMM)
Utilizes 200 Mb/s and 266 Mb/s DDR SDRAM components
64MB (8 Meg x 64 [H]); 128MB (16 Meg x 64, [H] and [HD]); 256MB (32 Meg x 64 [HD]); 512MB
(64 Meg x 64 [HD])
VDD= VDDQ= +2.5V ±0.2V
VDDSPD = +2.2V to +5.5V
2.5V I/O (SSTL_2 compatible)
Commands entered on each positive CK edge
DQS edge-aligned with data for READs; center-aligned with data for WRITEs
Internal, pipelined double data rate (DDR) architecture; two data accesses per clock cycle
Bi-directional data strobe (DQS) transmitted/received with data—i.e.,source-synchronous data capture
Differential clock inputs (CK and CK# - can be multiple clocks, CK0/CK0#, CK1/CK1#, etc.)
Four internal device banks for concurrent operation
64MB, 128MB, 256MB, 512MB (x64) 200-Pin DDR SDRAM SODIMMs
