154
8575
8575
N/B Maintenance
N/B Maintenance
-PCIRST
Q19
DTC144TKA
IDE_RST#
JS5
C273
4.7µ
C258
0.1µ
+5VS
41, 42
1
IDE_PDA[0:2], IDE_PDCS3#
U14
MuTIOL
Media I/O
Controller
SiS961
P14
IDE_PDD[0:15]
IDE_PDIOR#
IDE_PDIOW#
IDE_PDDACK#
IDE_PDCS1#
IDE_PDDREQ
IDE_IRQ14
IDE_PIORDY
+5VS
R144
4.7K
+5VS
39
R200
470
D19
PG1102W
R781 33
RP42, PR45
10*8
J19
P17
27
2~18
33,35,36,38
25
23
29
37
21
31
+5VS
R215
10K
R1
R1
R214
10K
Q18
DTC144TKA
RP528 33*4
R212 10
R213 22
R211 22
R205 82
R210 82
PDD[0:15]
PDA[0:2], PDCS3#
PDIOR#
PDIOW#
PDDACK#
PDCS1#
PDDREQ
IRQ14
PIORDY
Primary EDIE Connector
C261
0.1µ
+5VS_HDD
JS4
R202 10
8.7 Hard Drive Test Error
Either an error message is shown, or the drive motor spins non-stop, while reading data from or writing
data to hard disk.
