178
8575
8575
N/B Maintenance
N/B Maintenance
Part Number Description Location(s)
561567170001 MANUAL;USER'S,EN,8575,N-B
461671600002 PACKING KIT;N-B,14.1",8175
227671600003 PAD;LCD/KB,ANIT-STATIC,8175
224670830002 PALLET;1250*1080*130,7521N
221671650001 PARTITION;AK BOX,8175
221671650008 PARTITION;AK BOX,TOP,8175
221671650005 PARTITION;BATT,AK BOX,8175
221671650006 PARTITION;FDD,AK BOK,BTM,8175
221671650004 PARTITION;FDD,AK BOX,8175
221671250003 PARTITION;PALLET,8170
221671650007 PARTITION;SIDE,AK BOX,8175
222668820001 PE BAG;ANTI-STATIC,170x270MM,ORC
332810000033 PWR CORD;125V/7A,2P,BLACK,AMERIC
565180626001 S/W;CD*1,DVD,WIN-DVD,INTERVIDEO
561860000022 SINGLE PAGE;GN,NOTE FOR BATTERY&
370101714501 SPC-SCREW;M1.7L4.5,NIB,K-HEAD
370102610401 SPC-SCREW;M2.6L4,K-HD,t0.8,NIB/N
370102610801 SPC-SCREW;M2.6L8,NIB,K-HD,t=1.1,
421671600006 WIRE ASSY;LCD,UNIPAC,14",XGA,817
P/N: 526267173009
8575 ID4 14” 8575 ID4 15”
Part Number Description Location(s)
541667170004 AK;04-EU,BOX,8575
346671600021 AL-FOIL;CONDUCTIVE,LCD-SAM_XGA,8
441999900062 BATT ASSY OPTION;LI,9-CELL,8575
442671700002 BATT ASSY;11.1V/6AH,LI,MSL,8575
221671640001 BOX;AK,8175
342671600006 BRACKET;LCD,L,15",8175
342671600004 BRACKET;LCD,R,15",8175
221671650011 CARTON;5 IN 1,8175
431671700001 CASE KIT;8575
451671600031 CD ROM ME KIT;8175
340671700001 COVER ASSY;8575
340671600012 COVER ASSY;DIMM,8175
340671600029 COVER ASSY;HDD,8175
340671600021 COVER ASSY;LCD,15",8175
344671600010 COVER;DUMMY,8175
344671600011 COVER;HINGE,8175
344671600043 DUMMY CARD;PCMCIA,8175
227671600005 END CAP;5 IN 1,LOWER,8175
227671600004 END CAP;5 IN 1,UPPER,8175
345671600018 GASKET;HEATSINK,K/B_PLATE,8175
451671600051 HDD ME KIT;8175
340671600019 HINGE;L,15",8175
340671600017 HINGE;R,15",8175
340671700002 HOUSING ASSY;8575
340671600039 HOUSING ASSY;CDROM,8175
9. Spare Parts List - 8
