N/B Maintenance
N/B Maintenance
Part Number Description Location(s)
441999900205 AC ADPT ASSY OPTION;8575
442671200004 AC ADPT ASSY;19V/4.74A,DELTA,817
541667170032 AK;EN,8575,UTILITY ONLY
346671700016 AL-FOIL;HDD,M/B,8575
242670800113 BFM-WORLD MARK;WINXP,7521N
340671600028 BRACKET ASSY;T/P,INSULATOR,8175
421015560001 CABLE ASSY;PHONE LINE,6P2C,W/Z C
272072153401 CAP;.015U ,CR,16V,10%,0603,X7R,S C152,C154,C172,C192
272075103702 CAP;.01U ,50V,+80-20%,0603,SMT C212,C213,C232,C26,C265,C
272075103401 CAP;.01U ,CR,50V ,10%,0603,X7R,S PC16,PC20,PC27,PC541
272075103401 CAP;.01U ,CR,50V ,10%,0603,X7R,S PC525,PC551
272005103401 CAP;.01U ,CR,50V,10%,0805,X7R PC519
272005103401 CAP;.01U ,CR,50V,10%,0805,X7R PC501,PC583
272073223401 CAP;.022U,CR,25V ,10%,0603,X7R,S PC10
272072104702 CAP;.1U ,16V,+80-20%,0603,SMT C143,C144,C145,C146,C147,
C
272073104701 CAP;.1U ,25V,+80-20%,0603,Y5V,S PC4,PC502
272075104701 CAP;.1U ,50V,+80-20%,0603,SMT C504,C506,C512,C513,C517,
C
272075104701 CAP;.1U ,50V,+80-20%,0603,SMT C106,C107,C108,C110,C111,
C
272072104402 CAP;.1U ,CR,16V,10%,0603,X7R,SM PC542,PC572
272003104701 CAP;.1U ,CR,25V ,+80-20%,0805,Y C803,C805,PC22,PC23,PC25
,
272075102701 CAP;1000P,50V ,+/-20%,0603,X7R,S C101,C130,C151,C153,C155,
C
272030102405 CAP;1000P,CR,3KV,10%,1808,X7R,TU C501,C502,C577
272075102403 CAP;1000P,CR,50V,10%,0603,X7R,SM C1,C11,C534,C9,PC13,PC23,
P
272075102403 CAP;1000P,CR,50V,10%,0603,X7R,SM PC28,PC29,PC521,PC527,PC
272075101701 CAP;100P ,50V ,+ -10%,0603,NPO,S PC22
8575-ID2/ID3/ID4/ID5 Common Spare Parts
Part Number Description Location(s)
272075101401 CAP;100P ,50V ,10%,0603,COG,SMT C4,C7
272075101401 CAP;100P ,50V ,10%,0603,COG,SMT C1,C122,C126,C37,C579,C78
272075100701 CAP;10P ,50V ,+-10%,0603,NPO,SM C196,C227,C246,C41,C43,C7
272075100302 CAP;10P ,CR,50V ,5%,0603,NPO,SM C701,C702
272021106501 CAP;10U ,10V ,20%,1210,X7R,SMT PC31
272021106501 CAP;10U ,10V ,20%,1210,X7R,SMT C100,C132,C133
272011106701 CAP;10U ,10V,+80-20%,1206,Y5V,S C10,C12,C14,C15,C16,C18,C
1
272012106701 CAP;10U ,16V ,+80-20%,1206,Y5U, C531,PC21
272012106701 CAP;10U ,16V ,+80-20%,1206,Y5U, C698,PC24,PC27,PC533,PC5
4
272022106701 CAP;10U ,16V,+80-20%,1210,Y5V,S PC1,PC2
272023106501 CAP;10U ,25V ,20%,1210,Y5U,SMT PC546,PC577
272073151301 CAP;150P ,CR,25V,5% ,0603,NPO,SM PC9
272073151301 CAP;150P ,CR,25V,5% ,0603,NPO,SM PC573
272431157507 CAP;150U ,TPC,6.3V,20%,H1.9,7343 PC12,PC30
272431157507 CAP;150U ,TPC,6.3V,20%,H1.9,7343 C17,C9,PC524,PC531,PC547
,
272431157508 CAP;150U ,UE,6.3V ,20%,7343,SP-C PC29
272075150301 CAP;15P ,CR,50V ,5% ,0603,NPO,S C291
272071105701 CAP;1U ,CR,10V ,80-20%,0603,Y5 C10,C3,C509,C8
272071105701 CAP;1U ,CR,10V ,80-20%,0603,Y5 C136,C137,C138,C139,C140,
C
272001105402 CAP;1U ,CR,10V,10%,0805,X5R,SM PC5
272003105701 CAP;1U ,CR,25V ,+80%-20%,0805, PC550
272002105701 CAP;1U ,CR,16V ,-20+80%,0805,Y5 C521,C546,PC566
272002225701 CAP;2.2U ,CR,16V ,+80-20%,0805,Y C283,C788,C804,C806
272012225702 CAP;2.2U ,CR,16V ,+80-20%,1206,Y C522
272012225702 CAP;2.2U ,CR,16V ,+80-20%,1206,Y C714
9. Spare Parts List - 13
