MiTAC 8575 - Page 187

186
8575
8575
N/B Maintenance
N/B Maintenance
Part Number Description Location(s)
341671200010 FINGER;EMI GROUND SMD FINGER,H=4 E501,E502
341671200010 FINGER;EMI GROUND SMD FINGER,H=4 E511,E518,E519,TP506
342671700001 FINGER;EMI GROUNDING SMD FINGER E1,E10,E2,E4,E5,E7,E8,E9
342672400007 FINGER;EMI GROUNDING SMD FINGER E501,E502,E503,E507,E520,
E
288003600001 FIR;HSDL3600#007,FRONT VIEW,10P, U2
295000010105 FUSE;1A,NORMAL,1206,SMT F1,F501,F503,F504
295000010116 FUSE;FAST, 10A, 86VDC, 6125,SMT PF501
295000010116 FUSE;FAST, 10A, 86VDC, 6125,SMT PF502
295000010029 FUSE;FAST,.75A,63V,1206,THIN FIL PF501
345671700009 GASKET;BRACKET T/P,8575
345671700010 GASKET;KB PLATE,8575
345671700011 GASKET;KB PLATE-1,8575
345671600016 GASKET;LCD-HINGE,8175
345671700019 GASKET;MIC,8575
345671700004 GASKET;USB,8575
340671700006 HEATSINK ASSY;N/B,8575
340671700016 HEATSINK ASSY;P4 CPU, 8575
344600000824 IC CARD CON PART;68P,IC11SA-BD-P
291000610032 IC SOCKET;32P,PLCC,TIN,W/O PEGS, U10
331650047803 IC SOCKET;BGA-PGA478B-SKT U1
282574373004 IC;74AHC373,OCT D-TRAN,TSSOP,20P U8
282574186002 IC;74AHCT1G86,SINGLE,XOR,SOT23,S U513
282074338402 IC;74CBTD3384,10 BIT BUS SW,TSOP U11
282574164002 IC;74VHC164,SIPO REGISTER,TSSOP, U517
284501032001 IC;ADM1032,TEMPERATURE MTR,SO8 U2
Part Number Description Location(s)
284500201002 IC;ALC201,AC97 CODEC,TQFP,48P U15
286308800006 IC;AME8800AEEV,VOL REG.,SOT23-5, U17
286308801002 IC;AME8801MEEV,VOL REG.,SOT23-5, U512
284508500002 IC;CM8500,3A BUS TERMINATOR,PTSS PU10
283400000003 IC;EEPROM,NM24C02N,2K,SO,8P U7
283450083001 IC;FLASH,256K*8-70,PLCC32,ST39SF
284583437003 IC;H8/F3437S,KBD CTRL,TQFP,100P,
286317812001 IC;HA178L12UA,VOLT REGULATOR,SC- PU507
284501893001 IC;ICS-1893,LAN-PHY,TQFP,64P,SMT U5
284593722001 IC;ICS93722,DDR ZERO DELAY CLOCK U9
284595200101 IC;ICS952001,TIMING CTL HUB FOR U508
286300811002 IC;IMP811,RESET CIRCUIT,4.38,SOT U515
286100393004 IC;LMV393,DUAL COMPARTOR,SSOP,8P PU514
286302951015 IC;LP2951ACM,VOLTAGE REGULATOR,S U506
286317099001 IC;LTC1709-9,PWM,QSOP,36P PU508
286303707001 IC;LTC3707,PWM SWITCH REG,SOOP,2 PU4
286303707001 IC;LTC3707,PWM SWITCH REG,SOOP,2 PU510
286104173001 IC;MAX4173F,I-SENSE AMP,SOT23,6P PU1
286300809002 IC;MAX809S,RESET CIRCUIT,2.9V,SO U12
286305258001 IC;MIC 5258-1.2BM5,LV12,LDO REG, U502
284501284001 IC;PAC1284-01Q,TERMIN. NETWK,QSO U501,U502
284587393002 IC;PC87393F,TQFP,100P U511
284501410008 IC;PCI1410AGGU,BGA144P U6
286309701001 IC;RT9701,POWER DISTRI SW,SOT23- U1,U3
286300431014 IC;SC431LCSK-.5,.5%,ADJ REG,SOT2 PQ510
9. Spare Parts List - 16
