188
8575
8575
N/B Maintenance
N/B Maintenance
Part Number Description Location(s)
411503400201 PWA;PWA-STINGRAY/INVERTER BD,MSL
271046037103 RES;.003,1.5W,1%,2512,SMT PR501,PR503
271046057102 RES;.005,1.5W,1%,2512,SMT PR502,PR504
271045087101 RES;.008 ,1W ,1% ,2512,SMT PR16
271045107101 RES;.01 ,1W ,1% ,2512,SMT PR4,PR506
271045107101 RES;.01 ,1W ,1% ,2512,SMT PR525
271045157101 RES;.015 ,1W ,1% ,2512,SMT PR515
271586026101 RES;.02 ,2W,1%,2512,SMT PR13
271002000301 RES;0 ,1/10W,5% ,0805,SMT L2
271002000301 RES;0 ,1/10W,5% ,0805,SMT L513
271071000002 RES;0 ,1/16W,0603,SMT PR17,PR522,PR523,R1,R511
,
271071000002 RES;0 ,1/16W,0603,SMT C305,C723,L538,PR1,PR524,
271071152101 RES;1.5K ,1/16W,1% ,0603,SMT R506,R579
271071152302 RES;1.5K ,1/16W,5% ,0603,SMT R64
271071100302 RES;10 ,1/16W,5% ,0603,SMT PR3
271071100302 RES;10 ,1/16W,5% ,0603,SMT PR514,PR521,R100,R101,R1
0
271071101101 RES;100 ,1/16W,1% ,0603,SMT R522,R536
271071101301 RES;100 ,1/16W,5% ,0603,SMT R231,R548,R566,R74,R789,R
271071104101 RES;100K ,1/16W,1% ,0603,SMT PR557,PR563
271071104302 RES;100K ,1/16W,5% ,0603,SMT PR508,PR518
271071104302 RES;100K ,1/16W,5% ,0603,SMT PR15,PR3,PR510,PR538,PR5
271071103101 RES;10K ,1/16W,1% ,0603,SMT PR12,PR19
271071103101 RES;10K ,1/16W,1% ,0603,SMT PR507,PR513,PR527,PR540,
P
271071103302 RES;10K ,1/16W,5% ,0603,SMT R10,R516
271071103302 RES;10K ,1/16W,5% ,0603,SMT PR506,R125,R138,R149,R15,
Part Number Description Location(s)
271071106301 RES;10M ,1/16W,5% ,0603,SMT R189
271071111101 RES;110 ,1/16W,1% ,0603,SMT R20
271071113101 RES;11K ,1/16W,1% ,0603,SMT PR8
271071113101 RES;11K ,1/16W,1% ,0603,SMT PR530
271071121211 RES;12.1K,1/16W,1% ,0603,SMT R578,R731,R732,R733,R734
271071127211 RES;12.7K,1/16W,1%,0603,SMT PR508
271071137271 RES;13.7K,1/16W,.1%,0603,SMT PR10,PR558
271071131101 RES;130 ,1/16W,1% ,0603,SMT R545
271071134701 RES;130K ,1/16W,0.1% ,0603,SMT PR560
271071147011 RES;147 ,1/16W,1% ,0603,SMT R549
271071151101 RES;150 ,1/16W,1% ,0603,SMT R109,R116,R21,R508,R553,R
271071151302 RES;150 ,1/16W,5% ,0603,SMT R503,R504
271071153101 RES;15K ,1/16W,1% ,0603,SMT PR13,PR14
271071153101 RES;15K ,1/16W,1% ,0603,SMT PR528,PR532,R720,R722
271071153301 RES;15K ,1/16W,5% ,0603,SMT R502,R503,R504,R505,R508,
R
271071153301 RES;15K ,1/16W,5% ,0603,SMT R107,R114,R269,R270
271071102102 RES;1K ,1/16W,1% ,0603,SMT PR19,R556,R95
271071102302 RES;1K ,1/16W,5% ,0603,SMT PR517
271071102302 RES;1K ,1/16W,5% ,0603,SMT PR509,PR537,R1,R174,R194,
271071105301 RES;1M ,1/16W,5% ,0603,SMT PR509,PR521,PR6,PR7,R528
271071105301 RES;1M ,1/16W,5% ,0603,SMT PR5,PR505,PR539,PR545,PR
271071222302 RES;2.2K ,1/16W,5% ,0603,SMT R552,R558,R672,R674
271071249111 RES;2.49K,1/16W,1% ,0603,SMT PR546
271012278101 RES;2.7 ,1/8W,1% ,1206,SMT R14
271071272101 RES;2.7K ,1/16W,1% ,0603,SMT PR9
9. Spare Parts List - 18
