N/B Maintenance
N/B Maintenance
Features
Fully supports provisions of IEEE 1394-1995 standard for high performance serial bus and IEEE 1394a-2000
Fully interoperable with firewire™ and i.LINK™ implementation of IEEE Std 1394
Fully compliant with openHCI requirements
Provides one IEEE 1394a-2000 fully compliant cable port at 100/200/400 megabits per second (Mbits/s)
Full IEEE 1394a-2000 support includes: connection debounce, arbitrated short reset, multispeed concatenation,
arbitration acceleration, fly-by concatenation, port disable/suspend/resume
Register bits give software control of contender bit, power class bits, link active control bit, and IEEE
1394a- 2000 Features
IEEE 1394a-2000 compliant common mode noise filter on incoming TPBIAS
Extended resume signaling for compatibility with legacy DV devices, and terminal- and register- compatibility
with TSB41LV01, allow direct isochronous transmit to legacy DV devices with any link layer even when root
Power-Down features to conserve energy in battery powered applications include: automatic device power
down during suspend, device power-down terminal, link interface disable via LPS, and inactive ports
powered down
Failsafe circuitry senses sudden loss of power to the device and disables the port to ensure that the device
does not load TPBIAS of the connected device and blocks any leakage path from the port back to
the device power plane
Software device Reset (SWR)
Industry leading low power consumption
Ultralow-power sleep mode
