Single chip audio CODEC with high S/N ratio (>90 dB)
18-bit ADC and DAC resolution
Compliant with AC’97 2.2 specification
Meet performance requirements for audio on PC2001 systems
18-bit stereo full-duplex CODEC with independent and variable sampling rate
4 analog line-level stereo input with 5-bit volume control: LINE_IN, CD, VIDEO, AUX
2 analog line-level mono input: PC_BEEP, PHONE_IN
Mono output with 5-bit volume control
Stereo output with 5-bit volume control
2 MIC inputs: Software selectable
Power management
3D Stereo Enhancement
Headphone output with 50mW/20ohm driving capability (ALC201)
Line output with 50mW/20ohm driving capability (ALC201A)
Headphone jack-detect function to mute LINE output
Multiple CODEC extension
MC’97 chained in allowed for multi-channel application
External Amplifier power down capability
Support S/PDIF out is fully compliant with AC’97 specification rev2.2
Features
