5312/5324 IP Phones
Mitel
®
5000 CP Phone User Guide Supplement for v3.2, September 2009 Page 7
5312/5324 IP Phones
The 5312/5324 IP phones function similar to the 5212/5224 IP phones on the 5000 CP system.
Prior to v3.2, the 5312/5324 IP phones were supported by 5000 CP system software, however,
when the phones came online, they simulated the 5212/5224 IP phones. For v3.2 and later, the
5312/5324 IP phones now come online as the appropriate model IP phone.
The 5312/53224 IP phones are full-feature, dual port phones that provide voice communication
over an IP network. Both phones have a back-lit liquid crystal display (LCD), display-assisted
feature access, on-hook dialing, 10 fixed feature buttons, and a Ring/Message Indicator. For
one-touch feature access, the 5312 IP Phone has 12 programmable buttons and the 5324 IP
Phone has 24 programmable buttons. Images of the phones appear below.
For installation information, refer to the Mitel 5312/5324 IP Phone Installation Guide, part
number 57009711. This document is shipped in the box with the phone.
For information and instructions for supported features, refer to the Mitel 5312/5324 IP Phone
User Guide, part no. 550.8035.
1 – Handset 5 – Dialpad buttons
2 – Display 6 – Programmable buttons
3 – Ring/Message Indicator 7 – External speaker
4 – Feature buttons
1
2
3
4
5
7
6
5312 IP Phone
1 2
4
5
7
6
3
5224 IP Phone

Other manuals for Mitel 5324

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Mitel 5324 and is the answer not in the manual?

Mitel 5324 Specifications

Processor and Memory IconProcessor and Memory
processor typeTNETV1055 (MIPS)
processor speed125 MHz
DSP speed165 MHz
RAM16 MB
ROM8 MB
Weight and Dimensions IconWeight and Dimensions
dimensions (phone only)9.1 in x 7.5 in x 3.5 in (23 cm x 19 cm x 9 cm)
weight (phone only)1.65 lbs or 0.75 kg
dimensions (packaged)9.8 in x 8.3 in x 3.9 in (25 cm x 21 cm x 10 cm)
weight (packaged)2.49 lbs or 1.13 kg
