5320 IP Phone
Page 6 Mitel
®
5000 CP Phone User Guide Supplement for v3.2, September 2009
5320 IP Phone
The 5320 IP phone is a full-feature, dual port phone that provides voice communication over an
IP network. The phone has a 160 x 320 (pixels) liquid crystal display (LED), self-labeling
programmable buttons, on-hook dialing, and a Ring/Message Indicator.
For one-touch feature access, the 5320 IP Phone has11 programmable buttons, and 10 fixed
feature buttons to access commonly used features such as Transfer, Redial, Mute, etc. An
image of the 5320 IP phone is shown below.
The 5320 IP phone functions similar to the 5330 IP phone on the 5000 CP system, but includes
the following functional differences:
The 5320 requires 5000 CP v3.2 or later system software. It is not backward compatible
with earlier versions of system software.
The 5320 does not have a backlit display.
The top three buttons on the 5320 do not have LEDs.
The 5320 does not support a cordless module or cordless devices.
The 5320 has fewer programmable keys and does not support multiple pages of
programmable keys.
T
For installation information, refer to the Mitel 5320 IP Phone Installation Guide, part number
57010765. This document is shipped in the box with the phone.
For information and instructions for supported features, refer to the Mitel 5320/5330/5340 IP
Phone User Guide, part no. 550.8123.
1 – Handset 5 – Feature buttons
2 – Programmable buttons 6 – Dialpad buttons
3 – Display 7 – Navigation page buttons
4 – Ring/Message Indicator 8 – External speaker
NOTE
The display enhancements for the 5330 and 5340 IP phones are also supported
on the 5320 IP phone. See page 13 for more information.
1 2 3 4
5
6
8
7
