5330 and 5340 IP Phone Display Enhancements
Mitel
®
5000 CP Phone User Guide Supplement for v3.2, September 2009 Page 13
5330 and 5340 IP Phone Display Enhancements
For v3.2 and later, the 5000 CP supports two display enhancements for the 5330 and 5340 IP
phones:
• “Embedded Screen Saver” below
• “Text Size Control” on page 16
These features are also supported on the new 5320 IP phone (see page 6).
Embedded Screen Saver
For software version 3.2 and later, the 5330 and 5340 IP phones now include an embedded
screen saver that you can configure for your display.
By default the screen saver image is disabled. When your phone enters screen saver mode,
only the phone’s backlight dims. All 5340 and newer 5330 phones have a backlight.
You can enable the screen saver image and when your phone enters screen saver mode, the
phone’s backlight dims and the embedded screen saver image, similar to the one below,
appears on your display.
NOTE
The screen saver image is the same image you see when you press
(Applications) and select the About 5330/5340 IP Phone menu option.

Mitel 5324 Specifications

Processor and Memory

processor type	TNETV1055 (MIPS)
processor speed	125 MHz
DSP speed	165 MHz
RAM	16 MB
ROM	8 MB

Weight and Dimensions

dimensions (phone only)	9.1 in x 7.5 in x 3.5 in (23 cm x 19 cm x 9 cm)
weight (phone only)	1.65 lbs or 0.75 kg
dimensions (packaged)	9.8 in x 8.3 in x 3.9 in (25 cm x 21 cm x 10 cm)
weight (packaged)	2.49 lbs or 1.13 kg
