NSTALLING CABINET
Note: The following procedure must be performed for the feet at the front and for the
feet at the back:
1. Place two expander screws (D) with insulation bushing (E) and washer (F)
through the fixing irons and into the concrete floor, see Figure 8:Installing the
Expander Screw on page 15
2. Hammer the two expander screws into position.
3. Secure the two expander screws and earthquake bracing by tightening the
screws until the red caps snaps off, see Figure 9:Securing the Earthquake
Bracing on page 15
Note: The red cap snaps off when the screw has been tightened to the proper torque,
exposing a green washer. The green washer should be intact, with no breaks. If
the washer is found damaged during inspection, the screw must be verified to
have a minimum torque of 64 Nm (but not exceeding 68 Nm).
4. Proceed to the next installation stage, see 2.2.8 Fastening the Cabinets on page
16 .
2.2.8 FASTENING THE CABINETS
Fasten the cabinets to each other either side-by-side or back-to-back.
2.2.8.1 Fastening Cabinets Back-to-Back
Table 5 Mounting Set, Back-to-Back
24/BYB 501/2 Mounting Set, Back-to-Back, d=800
Pos. Title/Function Product Number Quantity
B SCREW 03/SBA 121 060/0160 12
A GUIDE PIN2 SXA 123 0327/2 6
