4 SAFETY MONITORING FUNCTIONS
Safety Logic Edit 4-39
Fig. 4-24: Area Input area Definition
(d) How to view the Area Input state
State variable M_SfIArea enables obtaining the Area Input state.
The Operation Check screen for the safety input also enables viewing it.
Diagonal point 1
（X1,Y1,Z1）
Diagonal point 2
（X2,Y2,Z2）
Z
Y
X
