Mitsubishi Electric FR-E740 SC EC Series User Manual

Wiring Main circuit connection
FR-E700SC EC 3 - 7
3.3.2 Terminal layout and wiring
Single-phase, 200V class
Three-phase, 400V class
FR-E720S-008SC to 030SC FR-E720S-050SC to 110SC
I002032E
I002033E
Tab. 3-3: Terminal layout and wiring
FR-E740-016SC to 095SC FR-E740-120SC and 170SC
I002034E
I002035E
FR-E740-230SC and 300SC
I002058E
—
Tab. 3-4: Terminal layout and wiring
Jumper
L1 N
M
3~
Motor
Power supply
Screw size
(M3.5)
Screw size (M3.5)
Jumper
Screw size (M4)
M
3~
Motor
Power supply
L1 N
Screw size
(M4)
N/-
P/+
Jumper
L1L2 L3
M
3~
Motor
Power supply
Screw size (M4)
Screw size (M4)
N/-
P/+
Jumper
Screw size (M4)
M
3~
Motor
Power supply
L1 L2 L3
Screw size (M4)
N/-
P/+
Jumper
Screw size
(230: M4,
300: M5)
L1 L2 L3
M
3~
Motor
Power supply
Screw size (230: M4, 300: M5)
