670
37 FUNCTIONS
37.16 RAS Functions
CPU module operation setting at error detection
The "Instruction Execution Error" setting under the "CPU Module Operation Setting at Error Detected" is applied only for
standard programs. A stop error always occurs in safety programs. (Even if "Continue" is selected, a stop error occurs.)
[CPU Parameter] [RAS Setting] [CPU Module Operation Setting at Error Detection]
■Applicable errors to the CPU module operation upon error detection setting
The following table lists the applicable errors to the setting that specifies the CPU module operation of when the specific
errors are detected in the SIL2 Process CPU.
CPU module operation setting
■Applicable errors to the CPU module operation setting
The following table lists the applicable errors to the setting that specifies the CPU module operation of when the specific
errors have occurred in each intelligent function module in the system using the SIL2 Process CPU.
Error name Error code
Memory card error 2120H, 2121H
Module verification error 2400H, 2401H
Fuse blown error 2420H
I/O number or network number specification error 2800H, 2801H, 2802H, 2803H, 2804H, 2805H, 2806H, 2807H, 2810H
Device, label, or buffer memory specification error 2820H, 2821H, 2822H, 2823H, 2824H
File name specification error 2840H, 2841H, 2842H
Operation error 3400H, 3401H, 3402H, 3403H, 3404H, 3405H, 3406H, 3420H, 3421H,
3422H, 3423H, 3440H, 3441H, 34A0H
Error name Error code
Module moderate error 1200H
Module major error 2441H, 2442H, 2450H
