Appendix 11 Target List and Operation Details of the Device/Label Access Service Processing Setting
937
A
Appendix 11 Target List and Operation Details of the
Device/Label Access Service Processing
Setting
Target list
This section describes the targets of the device/label access service processing setting.
Communication functions via the MC protocol
Among communication functions using the MC protocol, those to which the device/label access service processing setting
can be applied are as follows.
*1 Only the file register file can support it. (Other file access is always executed asynchronously from the program.)
*2 When registration/clear command is executed, it does not affect the scan time. However, since the serial communication module will
periodically access into the device memory of the CPU module when Function is enabled, it becomes the target for Device/Label access
service processing setting.
Applicable function Description
Functions to perform read/write to files accessed by programs When read/write is performed to the relevant files during execution of a
program, file inconsistency may occur. Therefore, such operation is performed
during the END processing.
Functions to perform write to devices/labels When write is performed to devices/labels during execution of a program, the
result of operation processing may become inconsistent. Therefore, such
operation is performed during the END processing.
Function Command
Device memory Multiple blocks batch read 0406 (000)
Multiple blocks batch write 1406 (000)
Batch read In units of bits 0401 (001)
In units of words 0401 (000)
Batch write In units of bits 1401 (001)
In units of words 1401 (000)
Random read 0403 (000)
Test (Random write) In units of bits 1402 (001)
In units of words 1402 (000)
Monitor 0802 (000)
Files New file creation
*1
1820 (0000)
File copy
*1
File password function incompatible 1824 (0000)
File password function compatible 1824 (0004)
File open
*1
File password function incompatible 1827 (0000)
File password function compatible 1827 (0004)
File read
*1
1828 (0000)
File write
*1
1829 (0000)
File close
*1
182A (0000)
Programmable controller CPU
monitoring
Registration
*2
0630 (0000)
Clear
*2
0631 (0000)
