3 EtherNet/IP Configuration Tool
3.1 Window Structure
■Structure setting check window
Verify the information of the network configuration settings saved on the RJ71EIP91 (EipConfData.BIN) against the
information of the network configuration settings of EtherNet/IP Configuration Tool (EipConfData.BIN) to check whether they
are the same.
[File] Ö [Verify]
Item Description Setting range
IP Address Displays the IP address of the RJ71EIP91.
User Name Displays the name.
(Fixed to MELSEC.)
Password Displays the password.
(Fixed to the RJ71EIP91.)
FTP Path Displays the FTP path.
[Verify] button Performs verification with the set details. The verification result is displayed in a
dialog box.
[Cancel] button Closes the structure setting check window.
