1 FUNCTIONS

1.7 Communications Using MODBUS/TCP

107

1.7 Communications Using MODBUS/TCP

MODBUS/TCP is a protocol for using MODBUS protocol messages on a TCP/IP network.

The RJ71EN71 and RnENCPU (network part) support the MODBUS/TCP slave function so that they can communicate with

MODBUS/TCP master devices.

For communications using MODBUS/TCP, refer to the following.

 MELSEiQ-R MODBUS/TCP Reference Manual

• When this function is used on the RJ71EN71 or RnENCPU (network part), check the firmware version of the

module. ( Page 406 Added and Enhanced Functions)

• This function is not available when the network type is set to "Q Compatible Ethernet" for the RJ71EN71.

(1) MODBUS/TCP master device

(2) RJ71EN71 or RnENCPU (network part)

(1) (2)

Request message

Response message

Ethernet
