1 FUNCTIONS

1.3 Communications Using the Predefined Protocol

Program examples

Classification Label name Description Device

Module label EN71_EE_1.bnCompletion_ConnectionOpen[1] Open completion signal (connection No.1) U0\G1900000.0

EN71_EE_1.uCompletion_EthernetInitialized_D.0 Initial status U0\G1900024.0

EN71_EE_1.bReady_PredefinedProtocol_D Predefined protocol ready U0\G1901002.0

Label to be defined Define global labels as shown below:
