APPX
Appendix 3 Buffer Memory
369
A
â– Predefined protocol registration (Un\G1901032 to Un\G1901047)
Whether protocol setting data is registered or not is stored.
All bits are set to 0 if the protocol setting data check result is abnormal.
• 0: No registration
• 1: Registered
The numbers in the table indicate protocol numbers.
Send/receive area for predefined protocol support function
â– Send/receive area for predefined protocol support function (Un\G1902000 to Un\G1904047)
This area is used for sending and receiving data during communication with predefined protocol.
User setting area for MODBUS/TCP function
â– User setting area for MODBUS/TCP function (Un\G1921024 to Un\G1929215)
This area is used for sending and receiving data during communications using MODBUS/TCP.
Address b15 b14 b13 b12 b11 b10 b9 b8 b7 b6 b5 b4 b3 b2 b1 b0
Un\G1901032 16151413121110987654321

Un\G1901039 128 127 126 125 124 123 122 121 120 119 118 117 116 115 114 113
Un\G1901040 to
Un\G1901047
Empty
