APPX
Appendix 3 Buffer Memory
357
A
Own node operation status storage area
■LED status (Un\G5189)
■Hub connection status area (Un\G5191 to Un\G5194)
The hub connection status of the Ethernet-equipped module is stored.
■IP address duplication status storage area (Un\G5200 to Un\G5206)
Information when IP address is duplicated is stored.
Area for sending/receiving instructions
■RECV instruction execution request (Un\G5301)
■Link dedicated instruction (Un\G5323 to Un\G5325)
The execution result of the link dedicated instruction is stored.
Address Description
Un\G5189 Stores the on/off status of the P ERR LED.
0: Off
1: On or flashing
Address Name Description
Un\G5191 Communication mode Stores the communication mode.
0: Half-duplex
1: Full-duplex
Un\G5192 Connection status Stores the connection status.
0: Hub is not connected or disconnected
1: Hub connected
Un\G5193 Communication speed Stores the communication speed.
0: Operating at 10BASE-T
1: Operating at 100BASE-TX
2: Operating at 1000BASE-T
Un\G5194 Disconnection count Stores the number of times the cable was disconnected.
Address Name Description
Un\G5200 Same IP address detection flag Stores IP address duplication status.
0: IP address not duplicated
1: IP address duplicated
Un\G5201 to Un\G5203 MAC address of the station already connected to the
network
Stores the MAC address of the station that has been
already connected to the network in the station with
duplicated IP address.
Un\G5201: 5th byte, 6th byte of the MAC address
Un\G5202: 3rd byte, 4th byte of the MAC address
Un\G5203: 1st byte, 2nd byte of the MAC address
"FFFFFFFFFFFFH" is stored in the station that has been
already connected to the network.
Un\G5204 to Un\G5206 MAC address of the station with the IP address already
used
Stores the MAC address of the station with duplicated IP
address in the station that has been already connected to
the network.
Un\G5204: 5th byte, 6th byte of the MAC address
Un\G5205: 3rd byte, 4th byte of the MAC address
Un\G5206: 1st byte, 2nd byte of the MAC address
"FFFFFFFFFFFFH" is stored in the station with duplicated
IP address.
Address Description
Un\G5301 Stores the RECV instruction execution request status of each channel in b0 to b7 (channel 1 to 8).
On: Requesting
Off: No request
Address Name Description
Un\G5323 ZNRD instruction execution result Stores the execution result of the ZNRD instruction.
0: Completed successfully
Other than 0: Completed with an error (An error code is
stored.)
