3 PROGRAMMING
3.2 Communication Example Using the Submaster Function
161
3
Setting in the master station
Connect the engineering tool to the CPU module of the master station and set parameters.
1. Set the CPU module as follows.
[Project] [New]
2. Click the [OK] button to add the module labels of the CPU module.
3. Set the master/local module as follows.
[Navigation window] [Parameter] [Module Information] Right-click [Add New Module]
Master station (station No.0) Local station (station No.1) Submaster station (station No.2)
Setting
To Next Page
