5. PARAMETERS
5 - 35
Control
mode
No./symbol/na
me
Setting
digit
Function
Initial
value
[unit]
PST
PC36
DMD
Status display
selection
_ _ x x Status display selection at power-on
This is used to select a status display shown at power-on.
00: Cumulative feedback pulse
01: Servo motor speed
02: Droop pulses
03: Cumulative command pulses
04: Command pulse frequency
05: Analog speed command voltage (Note 1)
06: Analog torque command voltage (Note 2)
07: Regenerative load ratio
08: Effective load ratio
09: Peak load ratio
0A: Instantaneous torque
0B: Within one-revolution position (1 pulse unit)
0C: Within one-revolution position (100 pulses unit)
0D: ABS counter
0E: Load to motor inertia ratio
0F: Bus voltage
10: Encoder inside temperature
11: Settling time
12: Oscillation detection frequency
13: Number of tough drives
14: Unit power consumption
15: Unit power consumption (increment of 1 kW)
16: Unit total power consumption (increment of 1 kWh)
17: Unit total power consumption (increment of 100 kWh)
00h
Note 1.
2.
It is for the speed control mode. It will be the analog speed limit voltage in
the torque control mode.
It is for the torque control mode. It will be the analog torque limit voltage in
the speed control mode and position control mode.
_ x _ _ Status display at power-on in corresponding control mode
0: Depends on the control mode
0h
Control mode Status display at power-on
Position Cumulative feedback pulses
Position/speed Cumulative feedback pulses/servo motor speed
Speed Servo motor speed
Speed/torque Servo motor speed/analog torque command
voltage
Torque Analog torque command voltage
Torque/position Analog torque command voltage/cumulative
feedback pulses
1: Depends on the first digit setting of the parameter
x _ _ _ For manufacturer setting 0h
Number of tough drive operations
